Maximum size of plate is 1,630mm x 1,336mm.
UV plate and thermal plate are available for you to lower production cost.
Furthermore, to improve the production efficiency, 64 channels, 128 channels and
256 channels laser are provided according to different printing speeds.
It can meet the demands of large books and periodicals, catalogues, yellow pages,
packaging processing and plate making center.
| Model | U1400 | U1400+ | T1400 | T1400+ |
|---|---|---|---|---|
| Exposing Method | External Drum | |||
| Imaging System | 64-channel | 128-channel | 64-channel | 256-channel |
| Discrete 405nm laser | Discrete 830nm laser | 825nm laser | ||
| Output Speed | 14 plates/hour | 22 plates/hour | 14 plates/hour | 19 plates/hour |
| 1,630×1,325mm, 2,400 dpi | ||||
| Plate Size | Max. 1,680×1,350 mm, Min. 650×550mm | |||
| Plate Thickness | 0.1 5 mm – 0.4 mm | |||
| Resolutions | 2,400dpi , 1,200dpi, (Option) | Standard: dual resolutions 2,400dpi and 1,200dpi, or 2,540dpi and 1,270dpi (Option) Variable high resolution option: maximm up to 10,000dpi at fast scan direction | ||
| Repeatability | 0.01mm | |||
| Interface | USB2.0 or USB3.0 ( USB2.0 is recommended ) | |||
| Plate Loading | Manual or automatic with autoloader | |||
| Net Weigh | 1,800KG | |||
| Device Size | 2,400×1,760×1,100 mm( L×W×H | |||
| Power Supply | Three phases:380V,Max power(Peak value):5.5W | Single phase: 220V, Max power (Peak value): 4.5KW | ||
| Environment | Operating temperature range:15-30℃ Recommended temperature:21-25℃ Humidity:<70% | |||
