Features: Small volume, high stability and perfect output quality.
UV plate and thermal plate are available for you to lower production cost
Furthermore, to improve the production efficiency, 32 channels, 48 cha nnels and64 channels laser are provided according to different printing speeds.
| Model | U424 | U432 | U448 | T424 | T432 | T448 |
|---|---|---|---|---|---|---|
| Exposing Method | External Drum | |||||
| Imaging System | 24-channel | 32-channel | 48-channel | 24-channel | 32-channel | 48-channel |
| Discrete 405nm laser | Discrete 830nm laser | |||||
| Output Speed | 16 plates/hour | 22 plates/hour | 28 plates/hour | 16 plates/hour | 22 plates/hour | 28 plates/hour |
| 800×660mm, 2,400dpi | ||||||
| Plate Size | Max. 800×690mm, Min. 300×400mm | |||||
| Plate Thickness | 0.15 mm – 0.3 mm | |||||
| Resolutions | 2,400dpi, 1,200dpi (Option) | |||||
| Repeatability | 0.01mm | |||||
| Interface | USB2.0 / USB3.0 ( USB2.0 is recommended ) | |||||
| Plate Loading | Manual | |||||
| Net Weight | 800KG | |||||
| Device Size | 1,900×1,200×1,000 mm( L×W×H ） | |||||
| Power supply | Single phase: 220V, Max power(Peak value): 4KW | |||||
| Environment | Operating temperature range:15-30℃ Recommended temperature:21-25℃ Humidity:<70% | |||||
