Maximum size of plate: 1,130mm*92Orim.
Features High stability and perfect output quality
It can meet most printers’ demands.
UV plate and thermal plate are available for you to lower production cost.
Furthermore, to improve the production efficiency. 32 channels. 48 ch annels and64 channels laser are provided according to different printing speeds
| Model | U832 | U848 | U864 | T832 | T848 | T864 |
|---|---|---|---|---|---|---|
| Exposing Method | External Drum | |||||
| Imaging System | 32-channel | 48-channel | 64-channel | 32-channel | 48-channel | 64-channel |
| Discrete 405nm laser | Discrete 830nm laser | |||||
| Output Speed | 16 plates/hour | 22 plates/hour | 28 plates/hour | 16 plates/hour | 22 plates/hour | 28 plates/hour |
| 1,030×800 mm, 2,400dpi | ||||||
| Plate Size | Max. 1,163×940 mm, Min. 300×400mm | |||||
| Plate Thickness | 0.15mm – 0.3mm | |||||
| Resolutions | 2,400dpi , 1,200dpi (Option) | |||||
| Repeatability | 0.01mm | |||||
| Interface | USB2.0 / USB3.0 ( USB2.0 is recommended ) | |||||
| Plate Loading | Manual | |||||
| Net Weigh | 900KG | |||||
| Device Size | 2,320×1,080×960mm( L×W×H ） | |||||
| Power supply | Single phase：220V，Max power(Peak value)：4KW | |||||
| Environment | Operating temperature range:15-30℃ Recommended temperature:21-25℃ Humidity:<70% | |||||
